| 品號 |
FIG |
支持範圍 |
ØD |
ØD1 |
Ød1 |
L |
θ |
WRENCH |
| BT30-SDC06-060K |
1 |
Ø2-6 |
14 |
17 |
27.5 |
60 |
|
M4 |
| BT30-SDC06-090K |
20 |
30.5 |
90 |
M4 |
| BT30-SDC12-080K |
2 |
Ø3-12 |
34 |
- |
34 |
80 |
|
M8 |
| BT40-SDC06-060K |
1 |
Ø2-6 |
14 |
16.3 |
23 |
60 |
|
M4 |
| BT40-SDC06-090K |
14 |
19.5 |
30 |
90 |
| BT40-SDC06-120K |
14 |
24 |
34.5 |
120 |
| BT40-SDC06-150K |
14 |
27.5 |
38 |
150 |
| BT40-SDC08-060K |
1 |
Ø3-10 |
22 |
24.3 |
23 |
60 |
|
M5 |
| BT40-SDC08-090K |
22 |
27.5 |
38 |
90 |
| BT40-SDC08-120K |
22 |
32 |
42.5 |
120 |
| BT40-SDC08-150K |
22 |
35.5 |
46 |
150 |
| BT40-SDC12-070K |
2 |
Ø3-12 |
34 |
- |
34 |
70 |
2.86° |
M8 |
| BT40-SDC12-090K |
- |
37 |
90 |
| BT40-SDC12-120K |
- |
39 |
120 |
| BT40-SDC12-150K |
- |
150 |
| BT50-SDC06-110K |
1 |
Ø2-6 |
14 |
21.5 |
32 |
110 |
|
M4 |
| BT50-SDC06-155K |
27 |
37.5 |
155 |
| BT50-SDC06-200K |
30 |
40 |
200 |
| BT50-SDC08-110K |
1 |
Ø3-10 |
22 |
29.5 |
40 |
110 |
|
M5 |
| BT50-SDC08-155K |
35 |
45.5 |
155 |
| BT50-SDC08-200K |
38 |
48 |
200 |
| BT50-SDC12-110K |
2 |
Ø3-12 |
34 |
- |
37 |
110 |
|
M8 |
| BT50-SDC12-155K |
- |
39 |
155 |
| BT50-SDC12-200K |
1 |
- |
41 |
200 |
